Features:
Ultra high power LED chip, CRI>80, 50 000 hours lifespan
High definition super clear lens
Aluminum alloy metal body with high structural strength, baking paint or sand blasting oxidation treatment,exiguity and unique design
Super heat conduction sink keeps the chip cool all the time, maximize the chip illumination and greatly increase the chip life
Endurable high quality power adaptor
Low consumption, save 80% more energy compared with traditional lighting fixtures
Manual zoom to get perfect logos
The projection direction of lamps can be adjusted.
The projection content can be customized and the pattern can be changed manually
Specification:
Input Voltage: AC:110-240V
Operation Frequency: 50-60HZ
Light source: High Power led chip
Led life span: 40000-50000h
CRI: Ra>80
Color temperature: 6000k
Material: High quality aluminum alloy, sandblasting oxide
Cooling: Natural Cooling
Installation: Ceiling/ wall mount type, floor standing
Manual zoom: gain best focus effect
Lens angle: 20° default
Projected spot diameter: 0.35m @ projection distance of 1meter (0.35:1 ratio)
Gobo color & pattern: Client customized
Power rate: as bellowing
Luminous lux: as bellowing
Suggested projection distance: as bellowing
Operating temperature: -40-55℃
Working humidity: 20%-80%
|
Model No.
|
Power
|
Luminous Flux
|
Projection Distance
|
Gobo size
|
N.W.(kg)
|
G.W.(kg)
|
|
LP15
|
15W
|
1300 lm
|
2-8m
|
37.5mm
|
1.1
|
1.4
|
|
LP25
|
25W
|
2200 lm
|
3-10m
|
37.5mm
|
1.3
|
1.6
|
|
LP35
|
35W
|
3200 lm
|
4-15m
|
37.5mm
|
1.4
|
1.7
|
|
LP55
|
55W
|
5000 lm
|
5-25m
|
37.5mm
|
2.1
|
2.5
|
|
LP15R
|
15W
|
1300 lm
|
2-8m
|
37.5mm
|
1.1
|
1.4
|
|
LP25R
|
25W
|
2200 lm
|
3-10m
|
37.5mm
|
1.3
|
1.6
|
|
LP35R
|
35W
|
3200 lm
|
4-15m
|
37.5mm
|
1.4
|
1.7
|
|
LP55R
|
55W
|
5000 lm
|
5-25m
|
37.5mm
|
2.1
|
2.5
|
